Question 1

Overview

Litware, Inc. is a financial company that has a main datacenter in Boston and 20 branch offices across the United States. Users have Android, iOS, and Windows 11 devices.

Existing Environment

Hybrid Environment

The on-premises network contains an Active Directory forest named litwareinc.com that syncs to a Microsoft Entra tenant named litwareinc.com by using Microsoft Entra Connect Sync.

All the offices connect to a virtual network named Vnet1 by using a Site-to-Site VPN connection.

Azure Environment

Litware has an Azure subscription named Sub1 that is linked to the litwareinc.com Microsoft Entra tenant. Sub1 contains resources in the East US Azure region as shown in the following table.

Name	Type	Description
Vnet1	Virtual network	Uses an IP address space of 192.168.0.0/20
GatewaySubnet	Virtual network subnet	Located in Vnet1 and uses an IP address space of 192.168.15.128/29
VPNGW1	VPN gateway	Deployed to Vnet1
Vnet2	Virtual network	Uses an IP address space of 192.168.16.0/20
SubnetA	Virtual network subnet	Located in Vnet2 and uses an IP address space of 192.168.16.0/24
Vnet3	Virtual network	Uses an IP address space of 192.168.32.0/20
cloud.litwareinc.com	Private DNS zone	None
VMScaleSet1	Virtual machine scale set	Contains four virtual machines deployed to SubnetA
VMScaleSet2	Virtual machine scale set	Contains two virtual machines deployed to SubnetA
storage1	Storage account	Has the public endpoint blocked
storage2	Storage account	Has the public endpoint blocked

A diagram of the resources in the East US Azure region is shown in the Azure Network Diagram exhibit. (Click the Azure Network Diagram tab.)

There is bidirectional peering between Vnet1 and Vnet2. There is bidirectional peering between Vnet1 and Vnet3. Currently, Vnet2 and Vnet3 cannot communicate directly.

Azure Network Diagram

Vnet1 uses an IP address space of 192.168.0.0/20. GatewaySubnet is in Vnet1 and uses an IP address space of 192.168.15.248/29. VPNGW1 is in to Vnet1.

SubnetA, VMScaleSet1 and VMScaleSet2 are in Vnet2. Bidirectional peering is configured between Vnet1 and Vnet2.

Vnet3 uses an IP address space of 192.168.32.0/20. Bidirectional peering is configured between Vnet1 and Vnet3.

storage1 and storage2 have public endpoints blocked.

Cloud.litwareinc.com is a private DNS zone

Requirements

Business Requirements

Litware wants to minimize costs whenever possible, as long as all other requirements are met.

Virtual Networking Requirements

Litware identifies the following virtual networking requirements:

Direct the default route of 0.0.0.0/0 on Vnet2 and Vnet3 to the Boston datacenter over an ExpressRoute circuit.
Ensure that the records in the cloud.litwareinc.com zone can be resolved from the on-premises locations.
Automatically register the DNS names of Azure virtual machines to the cloud.litwareinc.com zone.
Minimize the size of the subnets allocated to platform-managed services.
Allow traffic from VMScaleSet1 to VMScaleSet2 on the TCP port 443 only.

Hybrid Networking Requirements

Litware identifies the following hybrid networking requirements:

Users must be able to connect to Vnet1 by using a Point-to-Site (P2S) VPN when working remotely. Connections must be authenticated by Microsoft Entra ID.
Latency of the traffic between the Boston datacenter and all the virtual networks must be minimized.
The Boston datacenter must connect to the Azure virtual networks by using an ExpressRoute FastPath connection.
Traffic between Vnet2 and Vnet3 must be routed through Vnet1.

PaaS Networking Requirements

Litware identifies the following networking requirements for platform as a service (PaaS):

The storage1 account must be accessible from all on-premises locations without exposing the public endpoint of storage1.
The storage2 account must be accessible from Vnet2 and Vnet3 without exposing the public endpoint of storage2.

You need to prepare Vnet1 for the deployment of an ExpressRoute gateway. The solution must meet the hybrid connectivity requirements and the business requirements.

Which three actions should you perform in sequence for Vnet1? To answer, move the appropriate actions from the list of actions to the answer area and arrange them in the correct order.

Actions

Answer Area

Question 2

Overview

Litware, Inc. is a financial company that has a main datacenter in Boston and 20 branch offices across the United States. Users have Android, iOS, and Windows 11 devices.

Existing Environment

Hybrid Environment

The on-premises network contains an Active Directory forest named litwareinc.com that syncs to a Microsoft Entra tenant named litwareinc.com by using Microsoft Entra Connect Sync.

All the offices connect to a virtual network named Vnet1 by using a Site-to-Site VPN connection.

Azure Environment

Litware has an Azure subscription named Sub1 that is linked to the litwareinc.com Microsoft Entra tenant. Sub1 contains resources in the East US Azure region as shown in the following table.

Name	Type	Description
Vnet1	Virtual network	Uses an IP address space of 192.168.0.0/20
GatewaySubnet	Virtual network subnet	Located in Vnet1 and uses an IP address space of 192.168.15.128/29
VPNGW1	VPN gateway	Deployed to Vnet1
Vnet2	Virtual network	Uses an IP address space of 192.168.16.0/20
SubnetA	Virtual network subnet	Located in Vnet2 and uses an IP address space of 192.168.16.0/24
Vnet3	Virtual network	Uses an IP address space of 192.168.32.0/20
cloud.litwareinc.com	Private DNS zone	None
VMScaleSet1	Virtual machine scale set	Contains four virtual machines deployed to SubnetA
VMScaleSet2	Virtual machine scale set	Contains two virtual machines deployed to SubnetA
storage1	Storage account	Has the public endpoint blocked
storage2	Storage account	Has the public endpoint blocked

A diagram of the resources in the East US Azure region is shown in the Azure Network Diagram exhibit. (Click the Azure Network Diagram tab.)

There is bidirectional peering between Vnet1 and Vnet2. There is bidirectional peering between Vnet1 and Vnet3. Currently, Vnet2 and Vnet3 cannot communicate directly.

Azure Network Diagram

Requirements

Business Requirements

Litware wants to minimize costs whenever possible, as long as all other requirements are met.

Virtual Networking Requirements

Litware identifies the following virtual networking requirements:

Direct the default route of 0.0.0.0/0 on Vnet2 and Vnet3 to the Boston datacenter over an ExpressRoute circuit.
Ensure that the records in the cloud.litwareinc.com zone can be resolved from the on-premises locations.
Automatically register the DNS names of Azure virtual machines to the cloud.litwareinc.com zone.
Minimize the size of the subnets allocated to platform-managed services.
Allow traffic from VMScaleSet1 to VMScaleSet2 on the TCP port 443 only.

Hybrid Networking Requirements

Litware identifies the following hybrid networking requirements:

Users must be able to connect to Vnet1 by using a Point-to-Site (P2S) VPN when working remotely. Connections must be authenticated by Microsoft Entra ID.
Latency of the traffic between the Boston datacenter and all the virtual networks must be minimized.
The Boston datacenter must connect to the Azure virtual networks by using an ExpressRoute FastPath connection.
Traffic between Vnet2 and Vnet3 must be routed through Vnet1.

PaaS Networking Requirements

Litware identifies the following networking requirements for platform as a service (PaaS):

The storage1 account must be accessible from all on-premises locations without exposing the public endpoint of storage1.
The storage2 account must be accessible from Vnet2 and Vnet3 without exposing the public endpoint of storage2.

You need to connect Vnet2 and Vnet3. The solution must meet the virtual networking requirements and the business requirements.

Which two actions should you include in the solution? Each correct answer presents part of the solution.

NOTE: Each correct selection is worth one point.

On the peering from Vnet1, select Use the remote virtual network's gateway or Route Server .
On the peerings from Vnet2 and Vnet3, select Use the remote virtual network's gateway or Route Server .
On the peering from Vnet1, select Allow for Traffic to remote virtual network .
On the peerings from Vnet2 and Vnet3, select Allow for Traffic forwarded from remote virtual network .
On the peering from Vnet1, select Allow for Traffic forwarded from remote virtual network .

Select an answer above, then submit your vote. Reading or practicing does not cast a vote.

Question 3

Overview

Litware, Inc. is a financial company that has a main datacenter in Boston and 20 branch offices across the United States. Users have Android, iOS, and Windows 11 devices.

Existing Environment

Hybrid Environment

The on-premises network contains an Active Directory forest named litwareinc.com that syncs to a Microsoft Entra tenant named litwareinc.com by using Microsoft Entra Connect Sync.

All the offices connect to a virtual network named Vnet1 by using a Site-to-Site VPN connection.

Azure Environment

Litware has an Azure subscription named Sub1 that is linked to the litwareinc.com Microsoft Entra tenant. Sub1 contains resources in the East US Azure region as shown in the following table.

Name	Type	Description
Vnet1	Virtual network	Uses an IP address space of 192.168.0.0/20
GatewaySubnet	Virtual network subnet	Located in Vnet1 and uses an IP address space of 192.168.15.128/29
VPNGW1	VPN gateway	Deployed to Vnet1
Vnet2	Virtual network	Uses an IP address space of 192.168.16.0/20
SubnetA	Virtual network subnet	Located in Vnet2 and uses an IP address space of 192.168.16.0/24
Vnet3	Virtual network	Uses an IP address space of 192.168.32.0/20
cloud.litwareinc.com	Private DNS zone	None
VMScaleSet1	Virtual machine scale set	Contains four virtual machines deployed to SubnetA
VMScaleSet2	Virtual machine scale set	Contains two virtual machines deployed to SubnetA
storage1	Storage account	Has the public endpoint blocked
storage2	Storage account	Has the public endpoint blocked

A diagram of the resources in the East US Azure region is shown in the Azure Network Diagram exhibit. (Click the Azure Network Diagram tab.)

There is bidirectional peering between Vnet1 and Vnet2. There is bidirectional peering between Vnet1 and Vnet3. Currently, Vnet2 and Vnet3 cannot communicate directly.

Azure Network Diagram

Requirements

Business Requirements

Litware wants to minimize costs whenever possible, as long as all other requirements are met.

Virtual Networking Requirements

Litware identifies the following virtual networking requirements:

Direct the default route of 0.0.0.0/0 on Vnet2 and Vnet3 to the Boston datacenter over an ExpressRoute circuit.
Ensure that the records in the cloud.litwareinc.com zone can be resolved from the on-premises locations.
Automatically register the DNS names of Azure virtual machines to the cloud.litwareinc.com zone.
Minimize the size of the subnets allocated to platform-managed services.
Allow traffic from VMScaleSet1 to VMScaleSet2 on the TCP port 443 only.

Hybrid Networking Requirements

Litware identifies the following hybrid networking requirements:

Users must be able to connect to Vnet1 by using a Point-to-Site (P2S) VPN when working remotely. Connections must be authenticated by Microsoft Entra ID.
Latency of the traffic between the Boston datacenter and all the virtual networks must be minimized.
The Boston datacenter must connect to the Azure virtual networks by using an ExpressRoute FastPath connection.
Traffic between Vnet2 and Vnet3 must be routed through Vnet1.

PaaS Networking Requirements

Litware identifies the following networking requirements for platform as a service (PaaS):

The storage1 account must be accessible from all on-premises locations without exposing the public endpoint of storage1.
The storage2 account must be accessible from Vnet2 and Vnet3 without exposing the public endpoint of storage2.

You need to recommend a configuration for the ExpressRoute connection from the Boston datacenter. The solution must meet the hybrid networking requirements and the business requirements.

What should you recommend? To answer, select the appropriate options in the answer area.

NOTE: Each correct selection is worth one point.

Question 4

Overview

Litware, Inc. is a financial company that has a main datacenter in Boston and 20 branch offices across the United States. Users have Android, iOS, and Windows 11 devices.

Existing Environment

Hybrid Environment

The on-premises network contains an Active Directory forest named litwareinc.com that syncs to a Microsoft Entra tenant named litwareinc.com by using Microsoft Entra Connect Sync.

All the offices connect to a virtual network named Vnet1 by using a Site-to-Site VPN connection.

Azure Environment

Litware has an Azure subscription named Sub1 that is linked to the litwareinc.com Microsoft Entra tenant. Sub1 contains resources in the East US Azure region as shown in the following table.

Name	Type	Description
Vnet1	Virtual network	Uses an IP address space of 192.168.0.0/20
GatewaySubnet	Virtual network subnet	Located in Vnet1 and uses an IP address space of 192.168.15.128/29
VPNGW1	VPN gateway	Deployed to Vnet1
Vnet2	Virtual network	Uses an IP address space of 192.168.16.0/20
SubnetA	Virtual network subnet	Located in Vnet2 and uses an IP address space of 192.168.16.0/24
Vnet3	Virtual network	Uses an IP address space of 192.168.32.0/20
cloud.litwareinc.com	Private DNS zone	None
VMScaleSet1	Virtual machine scale set	Contains four virtual machines deployed to SubnetA
VMScaleSet2	Virtual machine scale set	Contains two virtual machines deployed to SubnetA
storage1	Storage account	Has the public endpoint blocked
storage2	Storage account	Has the public endpoint blocked

A diagram of the resources in the East US Azure region is shown in the Azure Network Diagram exhibit. (Click the Azure Network Diagram tab.)

There is bidirectional peering between Vnet1 and Vnet2. There is bidirectional peering between Vnet1 and Vnet3. Currently, Vnet2 and Vnet3 cannot communicate directly.

Azure Network Diagram

Requirements

Business Requirements

Litware wants to minimize costs whenever possible, as long as all other requirements are met.

Virtual Networking Requirements

Litware identifies the following virtual networking requirements:

Direct the default route of 0.0.0.0/0 on Vnet2 and Vnet3 to the Boston datacenter over an ExpressRoute circuit.
Ensure that the records in the cloud.litwareinc.com zone can be resolved from the on-premises locations.
Automatically register the DNS names of Azure virtual machines to the cloud.litwareinc.com zone.
Minimize the size of the subnets allocated to platform-managed services.
Allow traffic from VMScaleSet1 to VMScaleSet2 on the TCP port 443 only.

Hybrid Networking Requirements

Litware identifies the following hybrid networking requirements:

Users must be able to connect to Vnet1 by using a Point-to-Site (P2S) VPN when working remotely. Connections must be authenticated by Microsoft Entra ID.
Latency of the traffic between the Boston datacenter and all the virtual networks must be minimized.
The Boston datacenter must connect to the Azure virtual networks by using an ExpressRoute FastPath connection.
Traffic between Vnet2 and Vnet3 must be routed through Vnet1.

PaaS Networking Requirements

Litware identifies the following networking requirements for platform as a service (PaaS):

The storage1 account must be accessible from all on-premises locations without exposing the public endpoint of storage1.
The storage2 account must be accessible from Vnet2 and Vnet3 without exposing the public endpoint of storage2.

You need to provide connectivity to storage1. The solution must meet the PaaS networking requirements and the business requirements.

What should you include in the solution?

a private endpoint
a service endpoint
Azure Traffic Manager
Azure Front Door

Select an answer above, then submit your vote. Reading or practicing does not cast a vote.

Question 5

Overview

Litware, Inc. is a financial company that has a main datacenter in Boston and 20 branch offices across the United States. Users have Android, iOS, and Windows 11 devices.

Existing Environment

Hybrid Environment

The on-premises network contains an Active Directory forest named litwareinc.com that syncs to a Microsoft Entra tenant named litwareinc.com by using Microsoft Entra Connect Sync.

All the offices connect to a virtual network named Vnet1 by using a Site-to-Site VPN connection.

Azure Environment

Litware has an Azure subscription named Sub1 that is linked to the litwareinc.com Microsoft Entra tenant. Sub1 contains resources in the East US Azure region as shown in the following table.

Name	Type	Description
Vnet1	Virtual network	Uses an IP address space of 192.168.0.0/20
GatewaySubnet	Virtual network subnet	Located in Vnet1 and uses an IP address space of 192.168.15.128/29
VPNGW1	VPN gateway	Deployed to Vnet1
Vnet2	Virtual network	Uses an IP address space of 192.168.16.0/20
SubnetA	Virtual network subnet	Located in Vnet2 and uses an IP address space of 192.168.16.0/24
Vnet3	Virtual network	Uses an IP address space of 192.168.32.0/20
cloud.litwareinc.com	Private DNS zone	None
VMScaleSet1	Virtual machine scale set	Contains four virtual machines deployed to SubnetA
VMScaleSet2	Virtual machine scale set	Contains two virtual machines deployed to SubnetA
storage1	Storage account	Has the public endpoint blocked
storage2	Storage account	Has the public endpoint blocked

A diagram of the resources in the East US Azure region is shown in the Azure Network Diagram exhibit. (Click the Azure Network Diagram tab.)

There is bidirectional peering between Vnet1 and Vnet2. There is bidirectional peering between Vnet1 and Vnet3. Currently, Vnet2 and Vnet3 cannot communicate directly.

Azure Network Diagram

Requirements

Business Requirements

Litware wants to minimize costs whenever possible, as long as all other requirements are met.

Virtual Networking Requirements

Litware identifies the following virtual networking requirements:

Direct the default route of 0.0.0.0/0 on Vnet2 and Vnet3 to the Boston datacenter over an ExpressRoute circuit.
Ensure that the records in the cloud.litwareinc.com zone can be resolved from the on-premises locations.
Automatically register the DNS names of Azure virtual machines to the cloud.litwareinc.com zone.
Minimize the size of the subnets allocated to platform-managed services.
Allow traffic from VMScaleSet1 to VMScaleSet2 on the TCP port 443 only.

Hybrid Networking Requirements

Litware identifies the following hybrid networking requirements:

Users must be able to connect to Vnet1 by using a Point-to-Site (P2S) VPN when working remotely. Connections must be authenticated by Microsoft Entra ID.
Latency of the traffic between the Boston datacenter and all the virtual networks must be minimized.
The Boston datacenter must connect to the Azure virtual networks by using an ExpressRoute FastPath connection.
Traffic between Vnet2 and Vnet3 must be routed through Vnet1.

PaaS Networking Requirements

Litware identifies the following networking requirements for platform as a service (PaaS):

The storage1 account must be accessible from all on-premises locations without exposing the public endpoint of storage1.
The storage2 account must be accessible from Vnet2 and Vnet3 without exposing the public endpoint of storage2.

You need to restrict traffic from VMScaleSet1 to VMScaleSet2. The solution must meet the virtual networking requirements.

What is the minimum number of custom NSG rules and NSG assignments required? To answer, select the appropriate options in the answer area.

NOTE: Each correct selection is worth one point.

Minimum number of custom NSG rulesMinimum number of NSG assignments

Question 6

Note: This question is part of a series of questions that present the same scenario. Each question in the series contains a unique solution that might meet the stated goals. Some question sets might have more than one correct solution, while others might not have a correct solution.

After you answer a question in this section, you will NOT be able to return to it. As a result, these questions will not appear in the review screen.

You have an Azure subscription that contains an Azure Front Door Premium profile named AFD1 and an Azure Web Application Firewall (WAF) policy named WAF1. AFD1 is associated with WAF1.

You need to configure a rate limit for incoming requests to AFD1.

Solution: You configure a custom rule for WAF1.

Does this meet the goal?

Yes
No

Select an answer above, then submit your vote. Reading or practicing does not cast a vote.
